▊Sliding layer materials TEFPLAS®
TEFPLAS® G has excellent wear resistance, Lower starting friction force, suitable for hard shafts, hard anodized aluminum shafts.
| Materials | Friction coef. dry [u] | Max. static load [Mpa] | Max. dynamic load [Mpa] | Max. PV [N/mm2xm/s] | Max. Speed ,dry [m/s] | Operation temp. [℃] | |
| Continuous | Intermittent | ||||||
| TEFPLAS® G | 0.10-0.20 | 16 | 8 | 0.6 | 1.0 | 3.0 | ±200 |
***For operation under extreme high temperature, it is necessary to consider increasing the fitting clearance to avoid stagnation caused by the high temperature expansion of the shaft and bearing. Please contact us.
▊Bearing back material
The standard bearing back material is light-weight and high-strength aluminum alloy. When the bearing is used in applications with high requirements for corrosion resistance, it is recommended to use stainless steel back and TEFPLAS® G as the wear-resistant layer material;
